ARM嵌入式工控机

CPU

Rockchip  RK3568

Quad-core ARM Cortex-A55 64bit CPU,up to 2.0GHz

GPU

ARM G52 2EE GPU

SupportOpenGLES1.1/2.0/3.2,OpenCL2.0,Vulkan1.1, embedded high performance 2D acceleration hardware

NPU

 1.0TOPS@INT8

SupportCaffe/Mxnet/TensorFlow/TFLite/ONNX/Darknet models.

operating system

Linux Ubuntu 20.04

RAM

DDR4 4GB

Memory

eMMC 32GB

network

Dual 10/100 Ethernet ports

2.4GHz Wi-Fi 802. 11b/g/n

4G mobile network

GPS

GPS, GLONASS, BDS, Galileo and QZSS

Protocol: NMEA 0183

Data update rate: 1 Hz by default

Sensitivity:-162dBm

Receive frequency: 1575.42MHz

Acquisition Autonomous -146 dBm Tracking Autonomous -157 dBm

Accuracy: Autonomous @ open sky 10m

SIM

1*SIM slot Nano-SIM(4FF)

Displays

1*HDMI OUT 2.0 ,4K 60fps

Audio

1 * Ear output

RTC

Built-in real-time clock battery, supports scheduled power on/off.

USB

1*USB3.0 HOST

1 * USB 3.0 OTG

LED

1*PowerLED(RED),1*SystemLED(Blue, blinking)

2*DOLED

4*DI LED

Button

1*upgrade for OTA,REC

Serial Ports

2*RS232 ,2*RS485

IO

4*DI：dry/wet contact

--DI voltage range 0-36V (Max. 36V), High 5-36V, Low 0-2V

2*DO：Relay

--DO Max. 10A-277VAC/28VDC for NO,5A-250VAC for NC

4*AI：Analog quantity

--Voltage  range  0-10v;Analog  input  Current  range  4~20mA

Power Input

DC12V/2A (Max. 15V)

Connector: Jack Barrel Type DC5.5*2.1mm Round socket

Working Temperature

-10 - 70°C

Storage Temperature

-20 - 70 °C

Working Humidity

10%-80%

Dimension

160mm*85mm*28mm

Multi-media

Support for 4K 60fps H.265/H.264 Video decoding

Support for 1080P 100fps H.265/H.264 Video decoding

Support for 8 MISP, and support for HDR

Language

Default English, and you can download other languages online

InputMethod

Standard Android keyboard, optional third-party input method (Chinese, Korean, Japanese, etc.)
